Charging Stations for Electric Vehicles
Charging stations and chargers for electric cars and other electric vehicles rely on adhesives: The capacitors, voltage regulators and resistors on the charging boards must be mounted reliably resistant to shock and vibration. With additional conformal coatings, these components can be protected from temperature fluctuations, moisture and other climatic factors.
The same goes for the connector encapsulation in charging cables: Pin sealing protects the sensitive contacts and ensures efficient and fast charging of the batteries in the long term. Adhesives, sealants and casting compounds are ideally suited for these tasks.
The requirements for resistance to environmental influences can depend on many factors: In some cases, hard, resistant epoxy resins are required; in others, a more flexible, low-stress connection is preferred. Beside environmental conditions, the choice of casting or bonding compound is determined by factors such as substrates, surface characteristics and coefficients of thermal expansion of the materials used.
The choice of process can also affect the product recommendation. Especially UV-curing products enable a particularly efficient and rapid bonding process. For bonding applications with shaded zones that cannot be reached by light, the dual-curing products provide the most reliable curing results.
Adhesives protect the electronics in charging stations and chargers
In the following table you will find a selection of adhesives suitable for bonding in charging stations and chargers. Other products and customer-specific solutions are available on request. Technical data sheets can be downloaded by clicking on the adhesive name.
| Adhesive | Application Areas | Viscosity [mPas] | Base | Curing * | Special Properties |
|---|---|---|---|---|---|
|
3,000-5,000 | epoxy | UV secondary heat cure |
|
|
|
8,000-11,000 (Rheometer, 25 °C, 5s-1) | acrylate | UV VIS secondary moisture cure |
|
|
| - | 7,000-15,000 mix (LVT, 25°C, Sp. 4/30 rpm) | 2-part epoxy | thermal, room temperature |
|
|
| - | 3,000-4,000 mix (LVT, 25°C, Sp. 4/30 rpm) | 2-part epoxy | thermal room temperature |
|
|
|
30,000-45,000 (LVT, 25°C, Sp. 4/6 rpm) | epoxy | thermal |
|
|
| - | 200-400 (Rheometer, 25°C, 5s^-1) | acrylate | UV, VIS, moisture postcuring |
|
|
|
15,000-40,000 (Rheometer, 25°C, 10s^-1) | acrylate | UV VIS |
|
|
| - | 2,500-4,000 | acrylate | UV VIS secondary heat cure |
|
|
|
Structalit® 5811
|
- | Part A: 900-1,300, Part B: 100-350 | 2-part epoxy | thermal, room temperature |
|
*UV = 320 – 390 nm VIS = 405 nm
