UV Tube for Intensity and Dose Measurements

Precision UV Curing Sensor

The UV Tube is a robust sensor designed for industrial UV curing applications, particularly in coating and printing systems for cylindrical or round objects. It accurately measures both UV dose and intensity, ensuring optimal curing performance and consistent product quality. By monitoring lamp output in real-time, the UV Tube helps operators detect aging, contamination or underperforming lamps before they affect production. Compact and easy to integrate into industrial lines, this sensor provides reliable, repeatable results, making it an essential tool for maintaining efficiency and quality in demanding UV curing processes.

General Product Overview

Technical Information

Configuration	Options
UV Measuring range	UVA 315nm - 410nm UVB 280nm - 315nm UVC 230nm - 280nm UVV 395nm - 445nm UV LED 265nm - 495nm
Measuring range	1 - 2,000 mW/cm² (UV-A, -B, -C, -Vis) or 1 - 20,000 mW/cm² (= 20 W/cm²) (UV LED)
Sampling rate	5 msec (200/sec)
Recording cycle	90 sec.
Trigger time	400 sec.
Accuracy	± 5%
Position of photo diodes	Positioned on the longitudinal axis in 10 mm distances from each other
Display	none
Power source	LiPO 3,7 V permanently installed, Auto-Off after 1 minute, service life: approx. 100 hrs. Recharging is done with USB cable (scope of delivery)
Dimensions / Weight	UV Tube 3C and: Ø 25 mm, L= 60 mm / approx. 40 g UV Tube 3CT, 3C LED und 4C: Ø 25 mm, L= 80 mm / approx. 55 g
Operating temperature	0 to 45° C / 32° to 113° F , ambient temp. max. 110 °C / 230 ° F for 10s
Memory card	Micro SDHC
Scope of delivery	UV Tube, micro SD card, USB cable, PC software, plastic case
Calibration	Calibration is conform to DIN EN ISO/IEC 17025 and can be traced back to PTB (Phys. Technische Bundesanstalt). Each UV Tube Integrator is certified.
