UVC Special Lamp Designs
Tailor-made UV solutions for industry
As a manufacturer of UV lamps, we specialize in designing and producing UVC special lamps that meet the highest demands in water treatment, air purification, and industrial disinfection. In addition to standard UV lamps, our portfolio includes innovative custom lamp geometries that combine maximum efficiency with compact design.
A prime example are our U-bent UV lamps: their distinctive U-shape delivers nearly double the UV radiation at the same length or identical UV intensity at half the length. This enables the construction of compact, space-saving and high-performance UV disinfection systems for applications such as drinking water treatment, wastewater purification and swimming pool disinfection.
Beyond U-bent designs, we also manufacture Omega lamps, meander lamps and spiral lamps. These special UVC lamp types expand the possibilities of system engineering, allowing our customers to achieve the ideal balance of installation space, UV output and energy efficiency.
With our UVC special lamps, we provide tailor-made solutions for demanding UV disinfection applications – ensuring reliable inactivation of bacteria, viruses and spores in both municipal and industrial environments.
| Type | Arc Length | Overall Length | Power | UVC Power | Diameter |
|---|---|---|---|---|---|
| UVI 60 U 2G11 P 15/290 | 530mm | 290mm | 69W | 14W | 15mm |
| UVI 60 U 2G11 C P 15/305 | 560mm | 305mm | 69W | 18W | 15mm |
| UVI 80 U 2G11 C P 15/395 | 740mm | 395mm | 90W | 30W | 15mm |
| UVI 120 U 2G11 C P 15/469 | 888mm | 469mm | 110W | 35W | 15mm |
| UVI 150 U 2G11 C P 15/615 | 1180mm | 615mm | 135W | 45W | 15mm |
| UVI 170 U 2G11 C P 15/755 | 1530mm | 755mm | 170W | 60W | 15mm |
| UVI 200 U 2G11 C P 15/800 | 1620mm | 800mm | 180W | 63W | 15mm |
| UVI 260 U 2xG11 C P 19/1000 | 1920mm | 1000mm | 260W | 95W | 19mm |
